Bridging the Gap Between API and Drug Product

DS-DP co-processing is used extensively at CfPC to align both API and drug product development and to overcome potential hurdles in drug development. In solid-dosage processes, the API is generally blended with excipients via wet or dry granulation. Co-processing is a relatively new area of particle engineering in which commonly used excipients can be combined with the API in a more deliberate and controlled manner to design a pharmaceutical composite material.1 2 This approach combines two or more materials in a specific way to produce a composite material with improved physical or chemical properties. A process can be designed to resolve some of the common issues related to solid dosage production, such as material fl ow, stability, compactibility, release profile, bioavailability, food effect, content uniformity, taste, and even containment issues related to potent or toxic compounds.

At CfPC, crystallization efforts and form selection of APIs are closely integrated with the requirements of overall product development. As an example, for amorphous compounds, the end-point API is an intermediate co-processed in a dispersion with suitable formulation excipients to provide enhanced physical and chemical properties, such as stability, flow, and bioavailability, as evidenced by increased solubility and dissolution.

Milling of
Bulk API

  • Dry Milling: co-mill jet mill
  • Wet Milling: beads milling KA mill sonication

Controlled
Crystallization Process

  • Growth dominated crystallization
  • Nucleation dominated crystallization
  • Nucleation + Growth
  • Spherical crystallization
  • Wet milling applications

DS-DP
Co-Processing

  • Spray dried dispersions
  • Microsphere formation
  • Excipient modified crystallization
  • Crystallization inside porous excipient(s)
